All About TATA Defence Combat LAMV 4×4

In partnership with Supacat of the UK, the India-based TATA Motors Defence Solutions created the LAMV (Light Armoured Multipurpose Vehicle), a new 4×4 light patrol vehicle. Book Your SSB Interview...

In partnership with Supacat of the UK, the India-based TATA Motors Defence Solutions created the LAMV (Light Armoured Multipurpose Vehicle), a new 4×4 light patrol vehicle.

TATA Defence Combat LAMV 4x4 1

The LAMV was initially made available to the public at the 2014 Defexpo defence expo in India. With its cutting-edge observation, monitoring, and communication systems, the LAMV can be operated successfully. This tactical battlefield advantage’s cutting-edge technology will have the essential operational setup to handle urban warfare and engagements on any surface. The modern modularly constructed 4×4 LAMV will have the “stretch potential” to include necessary modifications and maintain functional supremacy for the duration of its service life.

Also Read: Top 5 Vehicles Used By The Indian Army

Its indigenization mostly accounts for its low life cycle cost. With the existing standard vehicular aggregates, all major subsystems are interchangeable.

SSB Interview Live Classes 3

Armament

At Defexpo, a 12.7mm machine gun-equipped open-top turret located on top of the crew compartment was installed on the 4×4 LAMV. Additionally, the roof has a single hatch. A full complement of weapon stations and smoke grenade launchers are available for the 4×4 LAMC. The turret includes a 360° manual azimuth movement and NIJ (National Institute of Justice Ratings for Body Armor) class III ballistic protection for the front and side of the shooter. This armour, which is typically hard or semi-rigid in structure, defends against 7.62mm full-metal jacketed bullets (designated M80 by the US military), which have nominal masses of 9.7 g (150 gr.) and hit at a speed of 838 m/s (2,750 ft/s) or less.

  • TATA LAMV 4x4 1
  • TATA LAMV 4x4 3
  • TATA LAMV 4x4 2

Along with Level I through IIIA threats, it also offers defence against 223 Remington (5.56mm FMJ), 30 Carbine FMJ, and 12-gauge rifled slugs. Level III body armour is obviously only meant to be used in tactical circumstances where the threat requires such defence, such as barricade encounters employing sporting rifles.

AFCAT 2023 Live Classes 2

Design and protection

With a 1.5 Ton payload, the 4×4 LAMV has an 8 Ton GVW (Gross Vehicle Weight). Six people, including the staff, can sit there (Commander and Driver). Better internal volume is made possible by the front engine, ergonomically designed dashboard, and equipment panel. The monocoque composite material pod and full length high hardness steel bottom V Hull for blast protection are integrated into the 4×4 LAMV to safeguard the crew. For easier usability, the POD is side-tillable. Due to its ballistic hull design, unique armour protection, and rapid mobility, it provides the greatest level of survivability in high threat scenarios. For different levels of protection, see Stanag II (a) and (b) for blast protection and Stanag II for ballistic protection.

CDS 2023 Live Classes 1

Accessories

The driver and commander display units are provided for the crew in the pod, and there are provisions for integrating the electro optical system, radio, GPS, and driver assistance camera. These units are conveniently integrated on the dashboard. It has a cutting-edge ruggedized navigation unit with a GPS system and an Inertial positioning system in case the GPS is unavailable. The LAMV additionally has CCD cameras, Thermal Imagers, and Laser Range Finder devices with detection ranges of up to 10 km, recognition ranges of up to 6 km, and identification ranges of up to 3.5 km. Depending on the needs of the customer, the 4×4 LAMV can be fitted with an AFDSS (Automatic Fire Detection and Suppression System). At Defexpo 2014, a telescopic pole with surveillance systems mounted at the back of the 4×4 LAMV was installed.

NDA 2023 Live Classes 1

Specifications in brief

ArmamentOne 12.7mm machine gun
ArmorStanaga 4569
Designer CountryIndia
Combat Weight8000 Kg
Speed105km/hr
AccessoriesElectro Optic system, Radio, GPS, driver assistance camera, CCD cameras, day/night vision, laser range finder.
